ffmpeg avc from .jpgs of arbitrary dimensions, maintaining aspect ratio

20th Jan 2023 21:32 #31

Member

hmm, audio ? maybe later using source filter "bas" ?

if joining videos, preference would be no crossfades naturally, so joining seems to be no problem, even mixing videos and images (quiet audio would be added)

I wanted to fade in or fade out audios from obvious reason, likeNLE's do (avoid abrupt sound changes, clicking), but that turn out to be not possible because audio in vapoursyth does not allow FrameEval() for audio samples. FrameEval() only allows vs.VideoNode to work with. So other modules are an option, I quickly check pydub, that might work, but did not go any further with it.

So without crossfades, concatenating video and images and rotate video (looks like mp4 oor mov only) and images if needed .
The approach would be to have an object called clip for example

that caries both video and audio, and allowing certain actions: trim, slicing, adding, multiplying, printing, that would also be carried for both video and audio. That could provide class Clip() and could be a separate module, called pairs.py:

Code:

class Clip:
    '''
     Creates class that carries both vs.VideoNode and vs.AudioNode.
     Using the same syntax as for vs.VideoNode on this class object for: trim/slice, add, multiply or print,
     the same operation is also done to the audio at the same time
     examples:
     from vapoursynth import core
     video = core.lsmas.LibavSMASHSource('video.mp4')
     audio = core.bas.Source('video.mp4')
     clip = Clip(video, audio)
     clip = clip[0] + clip[20:1001] + clip[1500:2000] + clip[2500:]
     #clip = clip.trim(first=0, length=1) + clip.trim(firt=20, last=1000) + clip.trim(1500, length=500) + clip.trim(2500)
     clip = clip*2
     clip = clip + clip
     print(clip)
     clip.video.set_output(0)
     clip.audio.set_output(1)
     '''

    def __init__(self, video = None, audio=None, attribute_audio_path=None):
        self.video = video
        self.audio = audio
        if self.video is None:
            self.video = core.std.BlankClip()
        if self.audio is None:
            if attribute_audio_path is None:
                raise ValueError('argument attribute_audio_path is needed to get default audio for images (could be a really short video')
            attr_audio = core.bas.Source(attribute_audio_path)
            length = int(attr_audio.sample_rate/self.video.fps*self.video.num_frames)
            self.audio = attr_audio.std.BlankAudio(length=length)

    def trim(self, first=0, last=None, length=None):
        afirst  = self.to_samples(first)    if first  is not None else None
        alast   = self.to_samples(last+1)-1 if last   is not None else None
        alength = self.to_samples(length)   if length is not None else None
        return Clip( self.video.std.Trim(first=first, last=last, length=length),
                     self.audio.std.AudioTrim(first=afirst,last=alast,length=alength)
                    )
    def to_samples(self, frame):
        return int((self.audio.sample_rate/self.video.fps)*frame)

    def __add__(self, other):
        return Clip(self.video + other.video, self.audio + other.audio)

    def __mul__(self, multiple):
        return Clip(self.video*multiple, self.audio*multiple)

    def __getitem__(self, val):
        if isinstance(val, slice):
            if val.step is not None:
                raise ValueError('Using steps while slicing AudioNode together with VideoNode makes no sense')
            start = self.to_samples(val.start) if val.start is not None else None
            stop =  self.to_samples(val.stop)  if val.stop  is not None else None
            return Clip( self.video.__getitem__(val),
                         self.audio.__getitem__(slice(start,stop))
                         )
        elif isinstance(val, int):
            start = self.to_samples(val)
            stop = int(start + self.audio.sample_rate/self.video.fps)
            return Clip( self.video[val],
                         self.audio.__getitem__(slice(start,stop))
                         )
    def __repr__(self):
        return '{}\n{}\n{}'.format('Clip():\n-------', repr(self.video), repr(self.audio))

    def __str__(self):
        return '{}\n{}\n{}'.format('Clip():\n-------', str(self.video), str(self.audio))

So get_clip function might look like this:

Code:

import pairs
ATTRIBUTE_AUDIO_PATH = r'D:\test2\some_very_short_video.m2ts'

def get_clip(path):
    #get video
    data = LOADER.get_data([str(path),])[0]
    video = data.clip
    if data.load_isError:
        raise ValueError(f'{data.load_log}\nload.py could not create vs.VideoNode from {path}')
    video = rotation_check(video, path, save_rotated_image=SAVE_ROTATED_IMAGES)
    video = video.std.AssumeFPS(fpsnum=FPSNUM, fpsden=FPSDEN)
    if BOX:  video = boxing(video, WIDTH, HEIGHT)
    else:    video = resize_clip(video, WIDTH, HEIGHT)
    video = video[0]*LENGTH if len(video)<5 else video

    #get_audio
    try:
        audio = core.bas.Source(str(path))
    except AttributeError:
        raise ImportError('Vapoursynth audio source plugin "BestAudioSource.dll" could not be loaded\n'
                          'download: https://github.com/vapoursynth/bestaudiosource/releases/tag/R1')
    except vs.Error as e:
        print(f'BestAudioSource could not load audio for: {path}\n{e}')
        clip = pairs.Clip(video, attribute_audio_path=ATTRIBUTE_AUDIO_PATH) #will generate quiet clip with desired parameters
    except Exception as e:
        print(f'Error loading audio for: {path}\n{e}')
        clip = pairs.Clip(video, attribute_audio_path=ATTRIBUTE_AUDIO_PATH)
    else:
        clip = pairs.Clip(video, audio)
    return clip

I used my load.py, that loads any filepath and uses proper plugin source, ffms2 indexes to temp folder, out of the way (could be deleted later). And also it remembers indexes, so it does not index again. I uploaded it here , you just need load.py and viewfunc.py, both can be downloaded. If you just run: import load; load.settings() it will launch GUI, where you can change preferences and it will always remember those settings. But you'd need to have tkinter installed, which comes with python, but not with portable python. Without tkinter UI settings would not work, load.py will work, but if you need to change plugin sources prereferences DEFAULT_PLUGIN_MAP within load.py would need to be manually changed.

Then tha main loop code to work with clips, you had it a bit different, but just how it works with that class Clip():

Code:

import load

LOADER = load.Sources()
paths = Path(DIRECTORY).glob("*.*")
path = get_path(paths)
if path is None:
    raise ValueError(f'Extensions: {EXTENSIONS}, not found in {DIRECTORY}')
clips = get_clip(path)    #loads obj class Clip() ! not vs.VideoNode
print('wait ...')
while 1:
    path = get_path(paths)
    if path is None:
        break
    clip = get_clip(path)   #again , it always loads obj class Clip(), not vs.VideoNode
    clips += clip  #class Clip() can add, where internally it adds video and audio

clips.video.set_output(0)
clips.audio.set_output(1)

Code also needs to define attribute video filepath that vapoursynth would get audio parameters from for quiet audio (if image is loaded). For some reason I cannot change samplerate from integer to float and cannot set default BlankAudio with float.

Code:

ATTRIBUTE_AUDIO_PATH = r'D:\test2\some_very_short_video.m2ts'

I hope I did not forgot anything, except maybe I had all scripts in portable directory/python_modules and use this script to encode output video, where it mixed images, mp4 and m2ts videos and rotated images, so this was encode.py:

Code:

import vapoursynth as vs
from vapoursynth import core
from subprocess import Popen, PIPE
from pathlib import Path
import sys
import os

def main(script, output_path):

    PATH        = Path(os.getcwd()) #Path(sys._MEIPASS) #if frozen
    script      = str(PATH / 'python_modules' / f'{script}')
    VSPipe      = str(PATH / 'VSPipe.exe')
    x264        = str(PATH / 'tools' / 'x264.exe')
    neroAacEnc  = str(PATH / 'tools' / 'neroAacEnc.exe')
    Mp4box      = str(PATH / 'tools' / 'MP4Box.exe')
    ##import loadDLL #if frozen
    ##VS_PLUGINS_DIR = PATH / 'vapoursynth64/plugins'
    ##isDLLS_LOADED, DLLS_LOG = loadDLL.vapoursynth_dlls(core, VS_PLUGINS_DIR)
    path        = Path(output_path)
    temp_video = str(path.parent / f'{path.stem}.264')
    temp_audio = str(path.parent / f'{path.stem}.m4a')

    vspipe_video = [VSPipe, '--container',  'y4m',
                            script,
                            '-']

    x264_cmd = [x264,       #'--frames',           f'{len(video)}',
                            '--demuxer',           'y4m',
                            '--crf',               '18',
                            '--vbv-maxrate',       '30000',
                            '--vbv-bufsize',       '30000',
                            '--keyint',            '60',
                            '--tune',              'film',
                            '--colorprim',         'bt709',
                            '--transfer',          'bt709',
                            '--colormatrix',       'bt709',
                            '--output',             temp_video,
                            '-']

    vspipe_audio = [VSPipe, '--outputindex', '1',
                            '--container',  'wav',
                            script,
                            '-']

    aac_cmd = [neroAacEnc,  '-ignorelength',
                            '-lc',
                            '-cbr', '96000',
                            '-if', '-',
                            '-of', temp_audio]


    mp4box_cmd = [Mp4box,   '-add' , f'{temp_video}',
                            '-add',  f'{temp_audio}#audio',
                            '-new',  output_path]

    p1 = Popen(vspipe_video, stdout=PIPE, stderr=PIPE)
    p2 = Popen(x264_cmd, stdin=p1.stdout, stdout=PIPE, stderr=PIPE)
    p1.stdout.close()
    p2.communicate()

    p1 = Popen(vspipe_audio, stdout=PIPE, stderr=PIPE)
    p2 = Popen(aac_cmd, stdin=p1.stdout, stdout=PIPE, stderr=PIPE)
    p1.stdout.close()
    p2.communicate()

    p = Popen(mp4box_cmd)
    p.communicate()

if __name__=='__main__':
    #scripts and outputs have full paths
    #python "encode.py" "media_to_show.py" "output.mp4"
    if len(sys.argv) > 2:
        main(sys.argv[1], sys.argv[2])

Last edited by _Al_; 21st Jan 2023 at 11:06.
