ffmpeg colorspace bt2020 convert to bt709, the color is not correct

[slick zheng]

i want to use ffmpeg to convert a video which with yuv420p10le(bt2020) to yuv420p(bt709), but the encoded video's color isn't correct compare to the original video

[Attachment 72889 - Click to enlarge]
this is the original video

[Attachment 72890 - Click to enlarge]
this is the encoded video
my command is add -pix_fmt:v yuv420p -colorspace:v 'bt709' -color_primaries:v 'bt709' -color_trc:v 'bt709' -color_range:v 'tv' flags to ffmpeg.
so how can i do with ffmpeg can do this conversion?

[ProWo]

Search for HDR to SDR with tonemap.
Can be done with clever Ffmpeg-GUI.


[Attachment 72894 - Click to enlarge]

In this example the source HDR is resized to 1280x720 and encoded with h264 (avc).
Use the newest beta (v3.1.3.01) for this.

[slick zheng]

Search for HDR to SDR with tonemap.
Can be done with clever Ffmpeg-GUI.


[Attachment 72894 - Click to enlarge]

In this example the source HDR is resized to 1280x720 and encoded with h264 (avc).
Use the newest beta (v3.1.3.01) for this.

i can't use this GUI, only can use ffmpeg CLI, do you know how to do same thing in CLI?

[ProWo]

i can't use this GUI, only can use ffmpeg CLI, do you know how to do same thing in CLI?

Here you go:

-vf zscale=t=linear:npl=100,format=gbrpf32le,zscale=p= 709,tonemap=hable:desat=2,zscale=t=709:m=709:r=tv, format=yuv420p

[slick zheng]

i can't use this GUI, only can use ffmpeg CLI, do you know how to do same thing in CLI?

Here you go:

-vf zscale=t=linear:npl=100,format=gbrpf32le,zscale=p= 709,tonemap=hable:desat=2,zscale=t=709:m=709:r=tv, format=yuv420p

this command has "No such filter: 'zscale'" error, my ffmpeg version is 6.0

[ProWo]

Post your full commandline.

[slick zheng]

Post your full commandline.

sorry i know this error is because my ffmpeg doesn't support libzimg2, so i compiled ffmpeg with libzimg2, and it works!
and now i want to apply this filter under nvidia gpu, so i try

./ffmpeg -y -vsync 0 -hwaccel cuda -hwaccel_output_format cuda -i UPL_1vKBpdd4iX_slice.mp4 -vf hwdownload,format=p010le,format=nv12,hwupload,scale_npp=format=yuv420p,zscale=t=linear:npl=100,format=gbrpf32le,zscale=p=709,tonemap=hable:desat=2,zscale=t=709:m=709:r=tv,format=yuv420p -c:v h264_nvenc output.mp4

but this has Impossible to convert between the formats supported by the filter 'Parsed_scale_npp_4' and the filter 'auto_scale_1' error, i guess this is because zscale doesn't support 10bit frame input? so i want to convert source input to yuv420p 8bit frame, but it doesn't work, could you give me some suggestions?

[ProWo]

Post your full commandline.

sorry i know this error is because my ffmpeg doesn't support libzimg2, so i compiled ffmpeg with libzimg2, and it works!
and now i want to apply this filter under nvidia gpu, so i try

./ffmpeg -y -vsync 0 -hwaccel cuda -hwaccel_output_format cuda -i UPL_1vKBpdd4iX_slice.mp4 -vf hwdownload,format=p010le,format=nv12,hwupload,scale_npp=format=yuv420p,zscale=t=linear:npl=100,format=gbrpf32le,zscale=p=709,tonemap=hable:desat=2,zscale=t=709:m=709:r=tv,format=yuv420p -c:v h264_nvenc output.mp4

but this has Impossible to convert between the formats supported by the filter 'Parsed_scale_npp_4' and the filter 'auto_scale_1' error, i guess this is because zscale doesn't support 10bit frame input? so i want to convert source input to yuv420p 8bit frame, but it doesn't work, could you give me some suggestions?

The zscale filter doesn't work with hardware acceleration.

[slick zheng]

Post your full commandline.

sorry i know this error is because my ffmpeg doesn't support libzimg2, so i compiled ffmpeg with libzimg2, and it works!
and now i want to apply this filter under nvidia gpu, so i try

./ffmpeg -y -vsync 0 -hwaccel cuda -hwaccel_output_format cuda -i UPL_1vKBpdd4iX_slice.mp4 -vf hwdownload,format=p010le,format=nv12,hwupload,scale_npp=format=yuv420p,zscale=t=linear:npl=100,format=gbrpf32le,zscale=p=709,tonemap=hable:desat=2,zscale=t=709:m=709:r=tv,format=yuv420p -c:v h264_nvenc output.mp4

but this has Impossible to convert between the formats supported by the filter 'Parsed_scale_npp_4' and the filter 'auto_scale_1' error, i guess this is because zscale doesn't support 10bit frame input? so i want to convert source input to yuv420p 8bit frame, but it doesn't work, could you give me some suggestions?

The zscale filter doesn't work with hardware acceleration.

bad message, so how can i do same color conversion thing with hardware acceleration?

[ProWo]

bad message, so how can i do same color conversion thing with hardware acceleration?

No clue ...

[slick zheng]

bad message, so how can i do same color conversion thing with hardware acceleration?

No clue ...

thanks bro

[pandy]

The zscale filter doesn't work with hardware acceleration.

Seem zscale is not compiled in his ffmpeg build - it can be queried from ffmpeg by this command:

ffmpeg -h filter=zscale > zscale.txt

[slick zheng]

The zscale filter doesn't work with hardware acceleration.

Seem zscale is not compiled in his ffmpeg build - it can be queried from ffmpeg by this command:

ffmpeg -h filter=zscale > zscale.txt

i have installed zscale and the command without cuda is work, but it's too slow, so i want to use gpu to accelerate, but seems zscale doesn't support gpu accelerate

[pandy]

The zscale filter doesn't work with hardware acceleration.

Seem zscale is not compiled in his ffmpeg build - it can be queried from ffmpeg by this command:

ffmpeg -h filter=zscale > zscale.txt

i have installed zscale and the command without cuda is work, but it's too slow, so i want to use gpu to accelerate, but seems zscale doesn't support gpu accelerate

Referred to

this command has "No such filter: 'zscale'" error, my ffmpeg version is 6.0

And yes - zscale is not GPU accelerated but it is quite fast - (for example faster than native to ffmpeg own scale and at the same time provide higher quality).

During transcode you have three basic steps, 1-st decode - this can be performed by HW, then processing - 2-nd processing and if zscale is used then CPU must be involved and 3-rd step is encoding - also can be performed by HW - usually 3-rd one is most computationally intensive and using HW acceleration is the most beneficial.

FFmpeg offer HW accelerated filter for tone mapping https://ffmpeg.org/ffmpeg-filters.html#tonemap_005fopencl - example of its usage is in https://superuser.com/questions/1549479/ffmpeg-4k-hdr-to-1080p-sdr-hardware-tonemap-co...version-opencl - so you need to combine HW decoding with HW tone mapping and HW encoding (my assumption based on your other threads).

Another possibility is to use https://ffmpeg.org/ffmpeg-filters.html#libplacebo for tone mapping

[slick zheng]

The zscale filter doesn't work with hardware acceleration.

Seem zscale is not compiled in his ffmpeg build - it can be queried from ffmpeg by this command:

ffmpeg -h filter=zscale > zscale.txt

i have installed zscale and the command without cuda is work, but it's too slow, so i want to use gpu to accelerate, but seems zscale doesn't support gpu accelerate

Referred to

this command has "No such filter: 'zscale'" error, my ffmpeg version is 6.0

And yes - zscale is not GPU accelerated but it is quite fast - (for example faster than native to ffmpeg own scale and at the same time provide higher quality).

During transcode you have three basic steps, 1-st decode - this can be performed by HW, then processing - 2-nd processing and if zscale is used then CPU must be involved and 3-rd step is encoding - also can be performed by HW - usually 3-rd one is most computationally intensive and using HW acceleration is the most beneficial.

FFmpeg offer HW accelerated filter for tone mapping https://ffmpeg.org/ffmpeg-filters.html#tonemap_005fopencl - example of its usage is in https://superuser.com/questions/1549479/ffmpeg-4k-hdr-to-1080p-sdr-hardware-tonemap-co...version-opencl - so you need to combine HW decoding with HW tone mapping and HW encoding (my assumption based on your other threads).

Another possibility is to use https://ffmpeg.org/ffmpeg-filters.html#libplacebo for tone mapping

yeah this is a good idea, but i don't know how to do this in one command, i try

./ffmpeg -y -vsync 0 -hwaccel cuda -hwaccel_output_format cuda -i UPL_1vKBpdd4iX_slice.mp4 -vf hwdownload,format=p010le,format=nv12,hwupload,scal e_npp=format=yuv420p,zscale=t=linear:npl=100,forma t=gbrpf32le,zscale=p=709,tonemap=hable:desat=2,zsc ale=t=709:m=709:r=tv,format=yuv420p -c:v h264_nvenc output.mp4

but seems zscale can't parse cuda's output, so i don't know how can do that you mentioned

[pandy]

yeah this is a good idea, but i don't know how to do this in one command, i try

./ffmpeg -y -vsync 0 -hwaccel cuda -hwaccel_output_format cuda -i UPL_1vKBpdd4iX_slice.mp4 -vf hwdownload,format=p010le,format=nv12,hwupload,scal e_npp=format=yuv420p,zscale=t=linear:npl=100,forma t=gbrpf32le,zscale=p=709,tonemap=hable:desat=2,zsc ale=t=709:m=709:r=tv,format=yuv420p -c:v h264_nvenc output.mp4

but seems zscale can't parse cuda's output, so i don't know how can do that you mentioned

As i don't have NVidia HW then i can't support you but i can tell what in my opinion you can do: first simplify command - try to remove unnecessary format conversion, at second i would try to play with zscale - sadly it doesn't report supported pixel formats (this is serious ffmpeg error i believe but this inconsistency in ffmpeg is quite common). Alternatively use HW accelerated tone mapping - examples are provided in libplacebo and tonemap_opencl .

[slick zheng]

yeah this is a good idea, but i don't know how to do this in one command, i try

./ffmpeg -y -vsync 0 -hwaccel cuda -hwaccel_output_format cuda -i UPL_1vKBpdd4iX_slice.mp4 -vf hwdownload,format=p010le,format=nv12,hwupload,scal e_npp=format=yuv420p,zscale=t=linear:npl=100,forma t=gbrpf32le,zscale=p=709,tonemap=hable:desat=2,zsc ale=t=709:m=709:r=tv,format=yuv420p -c:v h264_nvenc output.mp4

but seems zscale can't parse cuda's output, so i don't know how can do that you mentioned

As i don't have NVidia HW then i can't support you but i can tell what in my opinion you can do: first simplify command - try to remove unnecessary format conversion, at second i would try to play with zscale - sadly it doesn't report supported pixel formats (this is serious ffmpeg error i believe but this inconsistency in ffmpeg is quite common). Alternatively use HW accelerated tone mapping - examples are provided in libplacebo and tonemap_opencl .

thanks bro, i'll try your suggestion.

[Lathe]

Search for HDR to SDR with tonemap.
Can be done with clever Ffmpeg-GUI.


[Attachment 72894 - Click to enlarge]

In this example the source HDR is resized to 1280x720 and encoded with h264 (avc).
Use the newest beta (v3.1.3.01) for this.

Aha! I see you also helped another fellow with this too I was doing more research into what choices and parameters there are within the color space setting.
