What could be the problem behind this converted video?

[Unknown01]

Im trying to follow a tutorial that uses SVP's frame interpolation to make a 60 FPS video.

However, it seems there is something wrong with the video im using as a source for the whole process. When i use it with other videos it works flawlessly, but this video is different.

No matter what tool i use, the result will be something like this:



Forget the 60 fps tutorial, even if i use a software like Mediacoder or MeGUI to change the extension from MKV to MP4 or AVI the result is that.

I don't know how containers, encoding and codecs work but im going to guess the problem is somehow related to those.

[manono]

Probably the resolution. What is it?

If it's only Mod2, make it Mod4. And what is the script you're using?

[Unknown01]

Probably the resolution. What is it?

If it's only Mod2, make it Mod4. And what is the script you're using?

The resolution is 718x480. A pretty old video.

Mod2?
Mod4?

Not sure how to do that with MeGUI or MediaCoder.

And for the script im going to guess you mean the tutorial im following: Im using the script SVP generates.

[manono]

Since you're using SVP I figured you're also using AviSynth. Apparently it uses it 'under-the-hood' so to speak. But yes, I mean the script.

And it's the resolution that's the problem. You should either resize it to 720x480 before doing the filtering, or add 2 columns of black to one side. To add the black to the left side, edit the script to add:

AddBorders(2,0,0,0)

which will make it 720x480 and your image distortion will disappear.

[Unknown01]

Since you're using SVP I figured you're also using AviSynth. Apparently it uses it 'under-the-hood' so to speak. But yes, I mean the script.

And it's the resolution that's the problem. You should either resize it to 720x480 before doing the filtering, or add 2 columns of black to one side. To add the black to the left side, edit the script to add:

AddBorders(2,0,0,0)

which will make it 720x480 and your image distortion will disappear.

I added that to the script but nothing changed.

So i used handbrake to change it to 720x480. For some reason it is the only software that doesn't give me that weird result.

Now it works fine.

Thanks for the help.

[jagabo]

It's the decoder that's having a problem with the mod2 width of the frame. Use a different source filter or force a different decoder for the source codec.
