  1. Input movie:
    Code:
    Video
    ID                             : 1
    Format                         : AVC
    Format/Info                    : Advanced Video Codec
    Format profile                 : Main@L3.1
    Format settings, CABAC         : No
    Format settings, ReFrames      : 2 frames
    Codec ID                       : avc1
    Codec ID/Info                  : Advanced Video Coding
    Duration                       : 6mn 45s
    Bit rate mode                  : Constant
    Bit rate                       : 4 250 Kbps
    Nominal bit rate               : 5 985 Kbps
    Width                          : 1 280 pixels
    Height                         : 720 pixels
    Display aspect ratio           : 16:9
    Frame rate mode                : Variable
    Frame rate                     : 29.970 fps
    Minimum frame rate             : 29.970 fps
    Maximum frame rate             : 29.980 fps
    Color space                    : YUV
    Chroma subsampling             : 4:2:0
    Bit depth                      : 8 bits
    Scan type                      : Progressive
    Bits/(Pixel*Frame)             : 0.154
    Stream size                    : 205 MiB (97%)
    Language                       : English
    Material_Duration              : 405070
    Material_StreamSize            : 215208429
    Material_FrameCount            : 12140
    Color primaries                : BT.709-5, BT.1361, IEC 61966-2-4, SMPTE RP177
    Transfer characteristics       : BT.709-5, BT.1361
    Matrix coefficients            : BT.709-5, BT.1361, IEC 61966-2-4 709, SMPTE RP177
    Output movie:
    Code:
    Video
    ID                             : 1
    Format                         : AVC
    Format/Info                    : Advanced Video Codec
    Format profile                 : High@L3.1
    Format settings, CABAC         : Yes
    Format settings, ReFrames      : 5 frames
    Codec ID                       : avc1
    Codec ID/Info                  : Advanced Video Coding
    Duration                       : 6mn 45s
    Bit rate                       : 1 438 Kbps
    Maximum bit rate               : 3 550 Kbps
    Width                          : 1 280 pixels
    Height                         : 720 pixels
    Display aspect ratio           : 16:9
    Frame rate mode                : Variable
    Frame rate                     : 29.970 fps
    Minimum frame rate             : 29.960 fps
    Maximum frame rate             : 29.980 fps
    Color space                    : YUV
    Chroma subsampling             : 4:2:0
    Bit depth                      : 8 bits
    Scan type                      : MBAFF
    Bits/(Pixel*Frame)             : 0.052
    Stream size                    : 69.5 MiB (95%)
    Writing library                : x264 core 125 r2200+677M 3a754e7
    Encoding settings              : cabac=1 / ref=5 / deblock=1:-2:-1 / analyse=0x3:0x133 / me=umh / subme=10 / psy=1 / fade_compensate=0.00 / psy_rd=1.00:0.15 / mixed_ref=1 / me_range=24 / chroma_me=1 / trellis=2 / 8x8dct=1 / cqm=0 / deadzone=21,11 / fast_pskip=1 / chroma_qp_offset=-3 / threads=3 / lookahead_threads=1 / sliced_threads=0 / nr=0 / decimate=1 / interlaced=tff / bluray_compat=0 / constrained_intra=0 / fgo=0 / bframes=8 / b_pyramid=2 / b_adapt=2 / b_bias=0 / direct=3 / weightb=1 / open_gop=0 / weightp=0 / keyint=250 / keyint_min=25 / scenecut=40 / intra_refresh=0 / rc_lookahead=60 / rc=crf / mbtree=1 / crf=23.0000 / qcomp=0.60 / qpmin=0 / qpmax=69 / qpstep=4 / ip_ratio=1.40 / aq=1:1.00
    Encoded date                   : UTC 2012-10-28 09:52:27
    Tagged date                    : UTC 2012-10-28 09:52:27
    Matrix coefficients            : BT.709-5, BT.1361, IEC 61966-2-4 709, SMPTE RP177
    x264cli:
    Code:
    x264 --crf 23  --level 3.1 --preset veryslow --deblock -2:-1 --tune film --acodec aac --abitrate 70
    Log:
    Code:
    ffms [info]: 1280x720i 1:1 @ 30001/1001 fps (vfr)
    ffms [info]: color matrix: bt709
    audio [info]: opened libavcodec's libvo_aacenc encoder (70.0kbps, 16bits, 2ch, 44100hz, 1600 priming samples)
    x264 [warning]: input appears to be interlaced, enabling tff interlaced mode.
                    If you want otherwise, use --no-interlaced or --bff
    x264 [warning]: interlace + weightp is not implemented
    x264 [info]: using SAR=1/1
    x264 [warning]: frame MB size (80x46) > level limit (3600)
    x264 [warning]: DPB size (5 frames, 7065600 bytes) > level limit (4 frames, 6912000 bytes)
    x264 [warning]: MB rate (110293) > level limit (108000)
    x264 [info]: using cpu capabilities: MMX2 SSE2Fast SSSE3 FastShuffle SSE4.1 Cache64
    x264 [info]: profile High, level 3.1
    The output is quiet good; but can you specify what this error means
    Code:
    x264 [warning]: input appears to be interlaced, enabling tff interlaced mode.
                    If you want otherwise, use --no-interlaced or --bff
    ...& if I disable interlacing would it effect output positively or negatively.
    the video is kind off slowmo drama with no action scenes, however I want detail of character faces to be preserved highly thus I opted for --deblock -2:-1. What do you think?
    Quote Quote
  2. If your source is progressive it should be encoded as such. Encoding it as interlaced will blur the colors a bit. I don't know why MediaInfo shows your source is progressive and x264 thinks it's interlaced. Is there any possibility it switches from 720p to 1080i midstream?

    Encoding in interlaced mode may also eliminate Blu-ray playback as 720i isn't supported.
    Quote Quote
  3. Is there any possibility it switches from 720p to 1080i midstream?
    No.
