    Hey!

    I probably made a mistake some years ago when I was capturing a video from my camera. This video has many black lines. I would guess I made something wrong with the bottom field or top field first preference...
    As I think that there is no possibility to get back the lost fields I wanted to ask if anyone knows how I can "repair" this video by simply taking each existing field not for one but for two lines? I think that the picture will be unsharp then but it will look better than now...

    Anyone knows how I can solve this issue?

    Thank you!
    Best regards,
    Jarhead

    Quote Quote
  2. Member darkknight145's Avatar
    Join Date
    Feb 2007
    Location
    Australia
    Search PM
    Try De-interlacing it
    Quote Quote
  3. You have interlaced video. Each frame contains two half pictures (called fields) taken at different times -- one in all the even scanlines, one in all the odd scanlines. The camera moved between the time the two fields were taken. When you watch this on TV you see one field at a time. Computers show both fields. You can use a deinterlacing filter to convert the two fields into a single image. Some methods are better than others.
    Quote Quote
  4. And just to be clear, there's nothing wrong with that video. Unless you switched the field order somewhere along the line so that it plays all jerky/jumpy.
    Quote Quote
  5. Member
    Join Date
    Sep 2007
    Location
    Europe
    Search PM
    If you load the posted jpeg in VirtualDub and use the default deinterlace filter, you can try blend, duplicate field 1 and duplicate field 2 to see what it does.

    To me duplicate field 1 looks the best. The others look very blurry.
    Quote Quote
  6. Originally Posted by Chris K
    To me duplicate field 1 looks the best. The others look very blurry.
    Yes but that's probably just that particular frame. Ie, there was more motion (hence motion blur) during one field than the other. Or it could possibly be an artifact of saving the frame as a JPEG image. The two fields:

    Quote Quote
